ANSI TR-208 Solid Core Station Post Insulator Light Gray Glazed Customized Size

ANSI TR-208 Solid Core Station Post Insulator Light Gray Glazed Customized Size

  • High Light

    Customized Solid Core Station Post Insulator

    ,

    TR-208 Glazed Station Post Insulator

    ,

    ANSI Porcelain Electrical Insulators

  • Color
    Light Gray
  • Material
    Porcelain C-120
  • Application
    Transmission And Distribution Of Electric Power
  • Standard
    ANSI
  • Size
    Customized Size
  • Sample
    Provided
  • Oem
    YES
  • Pack
    Standard Export Packing
  • Place of Origin
    CHINA
  • Brand Name
    CPE
  • Model Number
    TR-208
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    WOODEN CRATE
  • Delivery Time
    35DAYS
  • Payment Terms
    T/T, L/C
  • Supply Ability
    3000PCS PER MONTH

ANSI TR-208 Solid Core Station Post Insulator Light Gray Glazed Customized Size



ANSI TR-208 Solid Core Station Post Insulator /light gray glazed





Description:



TR208 Station post insulator , the production process of porcelain insulator making plant involves the following major manufacturing operations:

Grinding → Clay making → Pugging → Moulding → Drying → Glazing → Kilning → Testing → Final product



ANSI TR-208 Solid Core Station Post Insulator Light Gray Glazed Customized Size 0



Technical requirements:



ANSI CLASS Creepage distance (mm) Torsion strength (N.m) cantilever strength (kN) Lower frequency flashover voltage Critical impulse flashover voltage Impulse withstand voltage (kV) Weight (kgs)
Dry(kV) Wet(kV) Positive (kV) Negative (kV)
TR-208 610 904 8.9 110 75 170 250 150 11





Application:



Ceramic Post insulators are used for insulation and support of live parts in outdoor power plants, distribution devices and electrical equipment of power frequency AC substations.





Competitive Advantages:



Pre-sales service:

Choose the proper reactor type

Installation recommendations and to provide technical information

Satisfied users of the special design requirements



After-sales service:

Offer professional equipment installation instructing

Provide spare parts for wearing parts(such as post insulator, bolt, etc.)
