42KV Brown Porcelain Lightning Arrester Insulator For Transmission Line

42KV Brown Porcelain Lightning Arrester Insulator For Transmission Line

  • High Light

    Brown Porcelain Lightning Arrester Insulator

    ,

    42KV Lightning Arrester Insulator

    ,

    Transmission Line Porcelain Lightning Arrester

  • Color
    Brown
  • Material
    Porcelain C-120
  • Application
    Transmission And Distribution Of Electric Power
  • Standard
    IEC
  • Product Name
    Arrester Porcelain Bushing
  • Sample
    Provided
  • Oem
    YES
  • Pack
    Standard Export Packing
  • Place of Origin
    CHINA
  • Brand Name
    CPE
  • Model Number
    1202,2202,3302
  • Minimum Order Quantity
    Negotiable
  • Price
    Negotiable
  • Packaging Details
    WOODEN CRATE
  • Delivery Time
    35DAYS
  • Payment Terms
    T/T, L/C
  • Supply Ability
    1000PCS PER MONTH

42KV Brown Porcelain Lightning Arrester Insulator For Transmission Line



42KV Brown Porcelain Lightning Arrester Insulator For Transmission Line





Descriptions:



We offer a complete line of porcelain bushings and bushing assemblies for transformer, switchgear, capacitor (2 flute to 14 flute) and special power apparatus applications. These durable, reliable bushings are high-quality porcelain designed to offer years of maintenance-free service.







Specifications:



Cat. No. Type Rated Voltage Bend breakage load (kN.m) Main dimensions
H D d1 Shed.no.
63915 Y5WZ-35(w) 42 4 965 240 112 22
66005 Y5WZ-66 66 4 1100 240 112 26








Applications:



Arrester bushings are used in transmmission line and distribution line.

42KV Brown Porcelain Lightning Arrester Insulator For Transmission Line 0





Ordering instructions:



1. If the transformer bushing is to be ordered, please provide rated voltage, rated current, rated frequency, length of oil end, installation method, length of cable crossing (very important), length of CT mounting position (very important), environmental pollution level, altitude, environmental temperature.

2. When the user has special requirements, the design can be carried out according to the user's requirements.
